| Part # | Model # | Type | Sub Category | Amps | Volts | Rackmount Length | Cord Length | Plug Type | Receptacle (QTY) | Local Meter | Universal | Upgradeable | RCM-B | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| U1073L | DU00X4W1-30PN67-2S02A9K00-S-A |
Show Description
rPDU, Basic Standard, 22.0kW, Variable Power Configuration, Vertical, (24) Locking IEC C13, (6) Locking IEC C19, Universal Inlet, Black Powder Coat.
|
Basic | Standard | Variable | Variable | 70in / 1778mm | None | Universal Input |
|
N | Y | N | N | |
| U1072L | DU00X4W1-36PNB7-1S02A9K00-S-A |
Show Description
rPDU, Basic Standard, 11.0kW, Variable Power Configuration, Vertical, (24) Locking IEC C13, (12) Locking IEC C19, Universal Inlet, Black Powder Coat.
|
Basic | Standard | Variable | Variable | 70in / 1778mm | None | Universal Input |
|
N | Y | N | N | |
| U1071L | DU00X2R1-18PB67-2S02A9F00-S |
Show Description
rPDU, Basic Standard, 22.0kW, Variable Power Configuration, Horizontal, (12) Locking IEC C13, (6) Locking IEC C19, Universal Inlet, Black Powder Coat.
|
Basic | Standard | Variable | Variable | 19in / 483mm | None | Universal Input |
|
N | Y | N | N | |
| NI30109 | LN03EFR0-TL21A0G10-3TL21A0E10-S |
Show Description
rPDU, Inline Monitored EC, 30A, 120/208V WYE, 8.6kW, Horizontal/Vertical, (1) NEMA L21-30R, 10ft power cord with L21-30P, Black Powder Coat.
|
Inline | Monitored | 30A | 120/208V WYE | 17in / 432mm | 10ft | NEMA Twist Lock |
|
Y | N | Y | N | |
| NI30108 | LN03EFR0-TL6A0G10-3TL6A0E10-S |
Show Description
rPDU, Inline Monitored EC, 30A, 208V, 4.9kW, Horizontal/Vertical, (1) NEMA L6-30R, 10ft power cord with L6-30P, Black Powder Coat.
|
Inline | Monitored | 30A | 208V | 17in / 432mm | 10ft | NEMA Twist Lock |
|
Y | N | Y | N | |
| I10499 | MN01D4W1-36CF13-3PS56B0A10-S-A |
Show Description
rPDU, Metered Upgradeable, 30A, 240/415V WYE, 17.2kW, Vertical, (36) Combination C13/C19, 10ft power cord with 3P+N+E (IP44), Black Powder Coat.
|
Metered | Upgradeable | 30A | 240/415V WYE | 70in / 1778mm | 10ft | IEC Splashproof |
|
Y | N | Y | N | |
| I10497 | MN01D4W1-36CF18-3TL15A0A10-S-A |
Show Description
rPDU, Metered Upgradeable, 30A, 208V DELTA, 8.6kW, Vertical, (36) Combination C13/C19, 10ft power cord with L15-30P, Black Powder Coat.
|
Metered | Upgradeable | 30A | 208V DELTA | 70in / 1778mm | 10ft | NEMA Twist Lock |
|
Y | N | Y | N | |
| I10496 | MN01D4W1-36CF18-3TL21A0A10-S-A |
Show Description
rPDU, Metered Upgradeable, 30A, 120/208V WYE, 8.6kW, Vertical, (36) Combination C13/C19, 10ft power cord with L21-30P, Black Powder Coat.
|
Metered | Upgradeable | 30A | 120/208V WYE | 70in / 1778mm | 10ft | NEMA Twist Lock |
|
Y | N | Y | N | |
| I10494 | MN01D4B1-36CF18-3TL6A0A10-S |
Show Description
rPDU, Metered Upgradeable, 30A, 208V, 4.9kW, Vertical, (36) Combination C13/C19, 10ft power cord with L6-30P, Black Powder Coat.
|
Metered | Upgradeable | 30A | 208V | 66in / 1683mm | 10ft | NEMA Twist Lock |
|
Y | N | Y | N | |
| I10493 | MN01DGW1-30CF18-6PS15D0A10-S-A |
Show Description
rPDU, Metered Upgradeable, 60A, 208V DELTA, 17.2kW, Vertical, (30) Combination C13/C19, 10ft power cord with 3P+E (IP67), Black Powder Coat.
|
Metered | Upgradeable | 60A | 208V DELTA | 70in / 1778mm | 10ft | IEC Watertight |
|
Y | N | Y | N | |
| I10492 | MN01DGW1-30CF18-6PS15B0A10-S-A |
Show Description
rPDU, Metered Upgradeable, 60A, 208V DELTA, 17.2kW, Vertical, (30) Combination C13/C19, 10ft power cord with 3P+E (IP44), Black Powder Coat.
|
Metered | Upgradeable | 60A | 208V DELTA | 70in / 1778mm | 10ft | IEC Splashproof |
|
Y | N | Y | N | |
| I10491 | MN01DGW1-30CF18-5CS15A0A10-S-A |
Show Description
rPDU, Metered Upgradeable, 50A, 208V DELTA, 14.4kW, Vertical, (30) Combination C13/C19, 10ft power cord with 3P+E CA, Black Powder Coat.
|
Metered | Upgradeable | 50A | 208V DELTA | 70in / 1778mm | 10ft | California Style |
|
Y | N | Y | N | |
| I10490 | MN01X4W1-36CF13-3PS56B0A10-S-A |
Show Description
rPDU, Basic Upgradeable, 30A, 240/415V WYE, 17.2kW, Vertical, (36) Combination C13/C19, 10ft power cord with 3P+N+E (IP44), Black Powder Coat.
|
Basic | Upgradeable | 30A | 240/415V WYE | 70in / 1778mm | 10ft | IEC Splashproof |
|
N | N | Y | N | |
| I10488 | MN01X4W1-36CF18-3TL15A0A10-S-A |
Show Description
rPDU, Basic Upgradeable, 30A, 208V DELTA, 8.6kW, Vertical, (36) Combination C13/C19, 10ft power cord with L15-30P, Black Powder Coat.
|
Basic | Upgradeable | 30A | 208V DELTA | 70in / 1778mm | 10ft | NEMA Twist Lock |
|
N | N | Y | N | |
| I10487 | MN01X4W1-36CF18-3TL21A0A10-S-A |
Show Description
rPDU, Basic Upgradeable, 30A, 120/208V WYE, 8.6kW, Vertical, (36) Combination C13/C19, 10ft power cord with L21-30P, Black Powder Coat.
|
Basic | Upgradeable | 30A | 120/208V WYE | 70in / 1778mm | 10ft | NEMA Twist Lock |
|
N | N | Y | N | |
| I10485 | MN01X4B1-36CF18-3TL6A0A10-S |
Show Description
rPDU, Basic Upgradeable, 30A, 208V, 4.9kW, Vertical, (36) Combination C13/C19, 10ft power cord with L6-30P, Black Powder Coat.
|
Basic | Upgradeable | 30A | 208V | 66in / 1683mm | 10ft | NEMA Twist Lock |
|
N | N | Y | N | |
| I10484 | MN01XGW1-30CF18-6PS15D0A10-S-A |
Show Description
rPDU, Basic Upgradeable, 60A, 208V DELTA, 17.2kW, Vertical, (30) Combination C13/C19, 10ft power cord with 3P+E (IP67), Black Powder Coat.
|
Basic | Upgradeable | 60A | 208V DELTA | 70in / 1778mm | 10ft | IEC Watertight |
|
N | N | Y | N | |
| I10483 | MN01XGW1-30CF18-6PS15B0A10-S-A |
Show Description
rPDU, Basic Upgradeable, 60A, 208V DELTA, 17.2kW, Vertical, (30) Combination C13/C19, 10ft power cord with 3P+E (IP44), Black Powder Coat.
|
Basic | Upgradeable | 60A | 208V DELTA | 70in / 1778mm | 10ft | IEC Splashproof |
|
N | N | Y | N | |
| I10482 | MN01XGW1-30CF18-5CS15A0A10-S-A |
Show Description
rPDU, Basic Upgradeable, 50A, 208V DELTA, 14.4kW, Vertical, (30) Combination C13/C19, 10ft power cord with 3P+E CA, Black Powder Coat.
|
Basic | Upgradeable | 50A | 208V DELTA | 70in / 1778mm | 10ft | California Style |
|
N | N | Y | N | |
| I10405 | MN01D4W1-36MR99-3TL14A0A10-S |
Show Description
rPDU, Metered Upgradeable, 30A, 120/208V, 5.7kW, Vertical, (20) IEC C13, (4) IEC C19, (12) NEMA 5-20R, 10ft power cord with L14-30P, Black Powder Coat.
|
Metered | Upgradeable | 30A | 120/208V | 70in / 1778mm | 10ft | NEMA Twist Lock |
|
Y | N | Y | N |
